CHAPTER 25 FLASH MEMORY
R01UH0146EJ0100 Rev.1.00
940
Sep 22, 2011
25.5 Programming Method
25.5.1 Controlling flash memory
The following figure illustrates the proc
edure to manipul
ate the flash memory.
Figure 25-7. Flash Memory Manipulation Procedure
Start
Manipulate flash memory
End?
Yes
Controlling TOOL0 pin and RESET pin
No
End
Flash memory programming
mode is set
958
960
