RL78/G13 CHAPTER 29 ELECTRICAL SPECIFICATIONS
R01UH0146EJ0100 Rev.1.00 1036
Sep 22, 2011
Caution The pins mounted depend on the product. Refer to 2.1.1 20-pin products to 2.1.14 128-pin products,
and 2.1.15 Pins for each product (pins other than port pins).
29.7.2 Temperature sensor characteristics
(T
A = −40 to +85°C, 2.4 V ≤ EVDD0 = EVDD1 ≤ VDD ≤ 5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Temperature sensor output voltage VTMPS25 Setting ADS register = 80H, TA = +25°C 1.05 V
Reference output voltage VCONST Setting ADS register = 81H 1.38 1.45 1.5 V
Temperature coefficient FVTMPS
Temperature sensor that depends on the
temperature
−3.6 mV/C
Operation stabilization wait time tAMP 5
μ
s
29.7.3 POR circuit characteristics
(T
A = −40 to +85°C, VSS = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
VPOR Power supply rise time 1.48 1.51 1.54 V Detection voltage
V
PDR Power supply fall time 1.47 1.50 1.53 V
Minimum pulse width TPW 300
μ
s
Detection delay time 350
μ
s
<R>
<R>
<R>
<R>
<R>
