RL78/G13 CHAPTER 21 VOLTAGE DETECTOR

R01UH0146EJ0100 Rev.1.00 900

Sep 22, 2011

21.5 Cautions for Voltage Detector

(1) Checking reset source

When a reset occurs, check the reset source by using the following method.

Figure 21-7. Checking reset source

Yes

Check reset source

Power-on-reset/external

reset generated

Reset processing by

watchdog timer

Reset processing by

voltage detector

WDTRF of RESF

Yes

Reset processing by

illegal instruction execution

Note

TRAP of RESF

Yes

Reset processing by

RAM parity error

Yes

LVIRF of RESF

RPERF of RESF

Reset processing by

illegal-memory access

Yes

IAWRF of RESF

Note When instruction code FFH is executed.

Reset by the illegal instruction execution not issued by emulation with the in-circuit emulator or on-chip

debug emulator.
