RL78/G13 CHAPTER 3 CPU ARCHITECTURE
R01UH0146EJ0100 Rev.1.00 114
Sep 22, 2011
3.1.1 Internal program memory space
The internal program memory space stores the program and table data.
The RL78/G13 products incorporate internal ROM (flash memory), as shown below.
Table 3-2. Internal ROM Capacity
Internal ROM Part Number
Structure Capacity
R5F100xA, R5F101xA (x = 6 to 8, A to C, E to G) 16384 × 8 bits (00000H to 03FFFH)
R5F100xC, R5F101xC (x = 6 to 8, A to C, E to G, J, L) 32768 × 8 bits (00000H to 07FFFH)
R5F100xD, R5F101xD (x = 6 to 8, A to C, E to G, J, L) 49152 × 8 bits (00000H to 0BFFFH)
R5F100xE, R5F101xE (x = 6 to 8, A to C, E to G, J, L) 65536 × 8 bits (00000H to 0FFFFH)
R5F100xF, R5F101xF (x = A to C, E to G, J, L, M, P) 98304 × 8 bits (00000H to 17FFFH)
R5F100xG, R5F101xG (x = A to C, E to G, J, L, M, P) 131072 × 8 bits (00000H to 1FFFFH)
R5F100xH, R5F101xH (x = E to G, J, L, M, P, S) 196608 × 8 bits (00000H to 2FFFFH)
R5F100xJ, R5F101xJ (x = F, G, J, L, M, P, S) 262144 × 8 bits (00000H to 3FFFFH)
R5F100xK, R5F101xK (x = F, G, J, L, M, P, S) 393216 × 8 bits (00000H to 5FFFFH)
R5F100xL, R5F101xL (x = F, G, J, L, M, P, S)
Flash memory
524288 × 8 bits (00000H to 7FFFFH)
The internal program memory space is divided into the following areas.
(1) Vector table area
The 128-byte area 00000H to 0007FH is reserved as a vector table area. The program start addresses for branch
upon reset or generation of each interrupt request are stored in the vector table area. Furthermore, the interrupt jump
address is a 64 K address of 00000H to 0FFFFH, because the vector code is assumed to be 2 bytes.
Of the 16-bit address, the lower 8 bits are stored at even addresses and the higher 8 bits are stored at odd addresses.
To use the boot swap function, set a vector table also at 01000H to 0107FH.
