Connecting the Printer
24
3
C Connect the other end of the cable to the printer's network, such as a hub.
D Attach the cable cover.
Reference
For details about network environment settings, see p.27 “Ethernet Con-
figuration”.
Reading the LED Lamps
1. Yellow: comes on when 100BASE-
TX is being used. It comes off when
10BASE-T is being used.
2. Green: comes on when the printer
is properly connected to the network.
ASH091S
AQC070S
To Next Page
