Paper Recommendations
45
5
Print Area
The following shows
the print
area for this printer. Be sure to set the print mar-
gins correctly by the application.
❖
Paper
A
Print area
B
Feed direction
C
Approx. 4.2 mm (0.17 inches)
D
Approx. 4.2 mm (0.17 inches)
Note
❒
The print area may vary depending
on the paper size, printer language
and printer driver settings.
65
67
