Uneven Density from Top to Bottom
The density is uneven from top to bottom.
• You can adjust the density of halftone images, but not that of solid fills.
Cause:
This may occur at high temperature or humidity.
Solution:
1. In the [Main Unit: Image Quality] group on the [Adjustment Settings for Operators] menu,
select 0206: [Density Difference: Across Feed].
Decreasing the value makes the area above the center denser and that below fainter.
Increasing the value makes the area above the center fainter and that below denser.
2. Turn off the power and the main power switch, and then turn the main power switch back
on.
The setting specified in step 1 will be in effect.
3. Print the image. Is the problem resolved?
Yes Finished!
No Replace the charge unit and photoconductor unit.
4. If unit replacement does not resolve the problem, contact your service representative.
Density Problems
45
