47
Menu Item 11:
A/D Converter Configuration (General Information)
Note: Access is restricted by a special password.
Features With the menu access switch open, you can
configure most of the parameters affecting
the following specifications:
– Toggling between Standard and Trade configurations
(for use in legal metrology)
– Verification scale interval e
– Scale interval d
– Minimum load
– Maximum load
– Maximum load for a given range
– Verification scale interval e for a given range
– User-definable weight units
These parameters are not reset when you restore the
factory defaults in the operating menu.
Parameters not listed above are not affected by your
choice of Standard or Trade configuration; the same
restrictions apply as for Sartorius weighing instruments
which cannot be configured.
Note on A/D Converter Configuration
A/D converter configuration is performed using the
numeric menu (weighing platform 1).
Important: The A/D converter can be configured only in
the service mode.
The maximum load for each weighing range must be
entered in an appropriate weight unit. Select the desired
weight unit for operation under menu line 11-7, “Weight
units”. The maximum load for each range must be a value
that can be displayed in any available weight unit.
Weight units that are accessible (or blocked) for use as
Weight unit 1 are also available (or blocked) for use as
Weight unit 2. The weight unit used for the configuration
cannot be blocked.
Checking and Configuring the Equipment for Use in Legal
Metrology:
