79
Setting the Overload Stops
1. Weighing Platforms with One Load Cell: Steel
Loosen the overload stops until the weight value displayed for the load on the
platform begins to decrease (stops touch the load plate support).
Then retract (tighten) the stops by 4 turn.
Platform nominal Test weight for Test weight for
capacity in Ib. middle stops in Ib. corner stops in Ib.
10 12 12
25 30 30
50 60 60
100 120 120
200 250 250
250 300 300
500 600 600
1000 1200 1200
