81
3. Weighing Platforms with Four Load Cells: Steel
Extend (loosen) the overload stops until the weight value displayed for the
load on the platform begins to decrease (i.e., until the stops touch the load
plate support).
Platform nominal Test weight for Test weight for
capacity in Ib. middle stops in Ib. corner stops in Ib.
1000 n/a 600
2500 n/a 1200
5000 n/a 2500
10000 n/a 4000
Alternatively, you can use a feeler gauge to adjust the corner stops.
In this case, weights are not required.
Platform nominal Feeler Gauge
capacity in Ib. in inch.
1000 0.015
2500 0.015
5000 0.020
10000 0.015
