82
4. Weighing Platforms with Four Load Cells: Stainless Steel
Extend (loosen) the overload stops until the weight value displayed for the load on
the platform begins to decrease (i.e., until the stops touch the load plate support).
Platform nominal Test weight for Test weight for
capacity in Ib. middle stops in Ib. corner stops in Ib.
50 n/a 50
100 n/a 100
200 n/a 100
250 n/a 120
500 n/a 200
1000 n/a 500
2500 n/a 1200
5000 n/a 2500
10000 n/a 5000
Alternatively, you can use a feeler gauge to adjust the corner stops.
In this case, weights are not required.
Platform nominal Feeler Gauge
capacity in Lb. in inch.
50 0.12
100 0.12
200 0.12
250 0.15
500 0.12
1000 0.15
2500 0.15
5000 0.20
10000 0.15
