108/219

Building Technologies Basic Documentation LMV27... CC1P7541en

12 Load output X74 pin 3 17.12.2018

12.2 Modulating operation

Actual value Voltage Curvepoint Display / output

value

Off DC 0 V --- Off

Ignition load DC 1 V P0 10%

Low-fire DC 2 V P1 20%

High-fire DC 10 V P9 100%

The values between low-fire and high-fire are interpolated in a linear manner.

12.3 2-stage operation

Actual value Voltage Curvepoint Display / output

value

Off DC 0 V --- Off

Stage 1 DC 5 V P1 P1

Stage 2 DC 10 V P2 P2

12.4 3-stage operation

Actual value Voltage Curvepoint Display / output

value

Off DC 0 V --- Off

Stage 1 DC 3 V P1 P1

Stage 2 DC 5 V P2 P2

Stage 3 DC 10 V P3 P3
