Siemens LMV27.100x2 User Manual

22/219
Building Technologies Basic Documentation LMV27... CC1P7541en
4 Technical Data 17.12.2018
4 Technical Data
4.1 LMV27 basic unit
Mains voltage AC 230 V -15 % / +10 %
Mains frequency 50 / 60 Hz ±6 %
Power consumption <30 W (typically)
Safety class I with parts according to II and III to
DIN EN 60730-1
Degree of protection IP00 to DIN EN 60529

Note
The burner or boiler manufacturer must
ensure degree of protection IP40 for the
LMV27 as per DIN EN 60529 through
adequate installation
Mode of operation
Type 2B in accordance with
DIN EN 60730-1
Rated surge voltage In accordance with DIN EN 60730-1
chapter 20 (OC III)
Voltage and current for the purposes of
the EMC emitted interference tests
The emitted interference measurement
test takes place with mains voltage and
maximum power consumption
4.1.1 Terminal loading Inputs
 Perm. mains primary fuse
(externally)
Max. 16 AT
 Unit fuse F1 (internally) 6.3 AT (DIN EN 60127 2 / 5)
 Mains supply: Input current depending on the operating state of the unit
Undervoltage
 Safety shutdown from operating
position at mains voltage
Approx. AC 186 V
 Restart on rise in mains voltage Approx. AC 195 V
Status inputs: Status inputs (with the exception of the safety loop) of the contact
feedback network (CFN) are used for system supervision and require mains-related
input voltage
 Input safety loop Refer to Terminal loading outputs
 Input currents and input voltages
- UeMax
- UeMin
- IeMax
- IeMin
UN +10 %
UN -15 %
1.5 mA peak
0.7 mA peak
 Contact material recommendation
for external signal sources (air
pressure switch, pressure switch-
min, pressure switch-max, etc.)
Gold-plated silver contacts
 Transition / settling behavior /
bounce
- Perm. bounce time of contacts
when switching on / off
Max. 50 ms
(after the bounce time, contact must stay
closed or open)
 UN AC 230 V
 Voltage detection
- On
- Off
AC 180...253 V
<AC 80 V
