79/219
Building Technologies Basic Documentation LMV27... CC1P7541en
8 Selection of operating mode 17.12.2018
8 Selection of operating mode
To facilitate straightforward adaptation of the LMV27 to different types of burners, the
LMV27 offers automatic configuration of the operating mode. This means that – derived
from parameter 201 – the most important settings relating to the operating mode are
made automatically. Very often in that case, the only manual settings to be made are
those for the air-fuel ratio control system. After selection of the operating mode,
parameters that are not required will be hidden (e.g. oil parameters when firing on gas).
No. Parameter
201
Burner operating mode (fuel train, modulating / multistage, actuators, etc.)
-- = undefined (delete curves)
1 = G mod
2 = Gp1 mod
3 = Gp2 mod
4 = Lo mod
5 = Lo 2-stage
6 = Lo 3-stage
7 = G mod pneu
8 = Gp1 mod pneu
9 = Gp2 mod pneu
10 = LoGp mod
11 = LoGp 2-stage
12 = Lo mod 2 fuel valves
13 = LoGp mod 2 fuel valves
14 = G mod pneu without actuator
15 = Gp1 mod pneu without actuator
16 = Gp2 mod pneu without actuator
17 = Lo 2-stage without actuator
18 = Lo 3-stage without actuator
19 = G mod gas actuator only
20 = Gp1 mod gas actuator only
21 = Gp2 mod gas actuator only
22 = Lo mod oil actuator only
23 = Ho mod separate circulation control
¹)
24 = Ho 2-stage separate circulation control
¹)
25 = Ho mod without circulation control
¹)
26 = Ho 2-stage without circulation control
¹)
27 = Ho 3-stage without circulation control
¹)
28 = G mod mech air actuator only ¹)
29 = Gp2 mod mech air actuator only
¹)
¹) Selected operating mode is not released for the LMV27.
With select: Error code 210 diagnostic code 0
