179/219

Building Technologies Basic Documentation LMV27... CC1P7541en

26 Parameter level 17.12.2018

ESC

mi n

Bild 156/0707

The warm settings for air-fuel ratio control of the LMV27 have now been configured.

26.11.12 Cold settings for multistage mode («Lo 2 stage» and « Lo 3 stage»)



Note

Refer to chapters Warm settings for «Lo 2-stage» and «Lo 3-stage»! But with no

flame, no actuator travel and no automatic operation after the settings have been

made.

If run is shown in the display, the following must be observed:

mi n

Bild 113/0707

Identification of start for setting the curve.



Note!

You now have the option of pressing

ESC

to continue with the cold setting for

the LMV27.
