26 Parameter level 17.12.2018
F
and
A
and
or
P
Vh
s
min %
Bild 110/0807
Press simultaneously
F
and
A
and
or to adjust speed n0 of the load
controller.
Example: 20.0
P
Vh
s
mi n %
Bild 111/0807
Release
F
and
A
.
The selected value will be adopted.
Example: 20.0
To the next curvepoint
P
Vh
mi n
s%
Bild 112/0707
Press
.
P9 appears blinking.
Curvepoint for high-fire.
Same procedure as with P0

Note!
If is pressed first, the display jumps to
90!
To the next curvepoint
Back to the previous
curvepoint.
P
Vh
mi n
s%
Bild 113/0707
Press
.
The display shows run (identification of start
for setting the curve parameters).

Note!
You now have the option of pressing
/
reset
to proceed with the warm settings (see
section Warm settings for modulating operation «G mod», «Gp1 mod», «Gp2 mod»
and «Lo mod») or pressing
ESC
to proceed with the cold settings (see section
Cold settings for «G mod», «Gp1 mod», «Gp2 mod» and «Lo mod») of the LMV27.
26.11.3 Setting curvepoints P0 and P9 for «G mod pneu», «Gp1 mod pneu»
and «Gp2 mod pneu»

Note
Refer to chapter Setting curvepoints P0 and P9 for modulating mode («G mod»,
«Gp1 mod», «Gp2 mod» and «Lo mod»)! Here, only the air requires adjustment with
A
.
