Building Technologies Basic Documentation LMV27... CC1P7541en
7 Basic unit LMV27 17.12.2018
7.2.2 Extraneous light
Extraneous light in Standby mode (phase 12) leads to start prevention, followed by a
restart. Extraneous light during the prepurge phase results in immediate lockout. If
extraneous light occurs during the shutdown phase, the LMV27 switches to the safety
phase.
One repetition is permitted. This means that if the error occurs again the next time the
system is shut down, the unit will initiate lockout.
Error
code
Diagnostic
code
Meaning for the LMV27
4 0 Extraneous light during the startup phase
1 Extraneous light during the shutdown phase
2 Extraneous light during the startup phase – start prevention
7.2.3 No flame at the end of safety time (TSA)
If no flame is established by the end of the first safety time, the unit initiates lockout.
Error
code
Diagnostic
code
Meaning for the LMV27
2 1
No flame at end of the first safety time
2
No flame at end of the second safety time
7.2.4 Flame intensity
The flame’s intensity can be displayed.
It is standardized from 0...100%.
No. Parameter
954 Intensity of flame
Note
Also refer to chapter Intensity of flame during curve settings.
7.2.5 Supervision of flame detector
Error
code
Diagnostic
code
Meaning for the LMV27
93 3 Short-circuit of flame detector
At the QRB / QRC flame detector’s input, the LMV27 checks the detector for short-
circuits in operation.
