Siemens LMV27.100x2 User Manual

161/219
Building Technologies Basic Documentation LMV27... CC1P7541en
26 Parameter level 17.12.2018
26.11.2 Setting curvepoints P0 and P9 for modulating mode («G mod», «Gp1
mod», «Gp2 mod» and «Lo mod»)

Note
Not all actuators used in the following example can be set, depending on the
selected operating mode.
Example of «G mod»
P
Vh
mi n
s%
Bild 102/0707
Display P0 appears flashing.
Curvepoint for ignition load.
F
P
Vh
mi n
s%
Bild 103/0707
Keep
F
depressed.
You are now in setting P0 of fuel setting F for
ignition position P0.
F
and
or
P
Vh
mi n
s%
Bild 104/0707
Press simultaneously
F
and or to
set ignition position P0 of the fuel damper.
Example: 30.0
P
Vh
mi n
s%
Bild 105/0707
Release
F
.
The selected value will be adopted.
Example: 30.0
A
P
Vh
mi n
s%
Bild 106/0707
Keep
A
depressed.
You are now in setting P0 of air actuator A for
ignition position P0.
A
and
or
P
Vh
mi n
s%
Bild 107/0707
Press simultaneously
A
and or to
set ignition position P0 of the air actuator.
Example: 22.0
P
Vh
mi n
s%
Bild 108/0707
Release
A
.
The selected value will be adopted.
Example: 22.0
F
and
A
P
Vh
s
min %
Bild 109/0807
Keep
F
and
A
depressed.
You are now in setting n0, speed n is for ignition
position n0
