Siemens LMV27.100x2 User Manual

23/219
Building Technologies Basic Documentation LMV27... CC1P7541en
4 Technical Data 17.12.2018
4.1.2 Terminal loading Outputs
Total contact loading:
 Rated voltage AC 230 V, 50 / 60 Hz
 Unit input current (safety loop) from:
- Fan motor contactor
- Ignition transformer
- Valves
- Oil pump / magnetic clutch
Max. 5 A
Individual contact loading:
Fan motor contactor
 Rated voltage AC 230 V, 50 / 60 Hz
 Rated current 2 A
 Power factor Cos >0.4
Alarm output
 Rated voltage AC 230 V, 50 / 60 Hz
 Rated current 1 A
 Power factor Cos >0.4
Ignition transformer
 Rated voltage AC 230 V, 50 / 60 Hz
 Rated current 2 A
 Power factor Cos >0.2
Fuel valves
 Rated voltage AC 230 V, 50 / 60 Hz
 Rated current 2 A
 Power factor Cos >0.4
Operation display
 Rated voltage AC 230 V, 50 / 60 Hz
 Rated current 0.5 A
 Power factor Cos >0.4
Safety valve (magnetic clutch / oil pump)
 Rated voltage AC 230 V, 50 / 60 Hz
 Rated current 2 A
 Power factor Cos >0.4
Connections for pressure switch
 Rated voltage AC 230 V, 50 / 60 Hz
 Rated current 1.5 mA
 Power factor ---
Power supply for pressure switch-max / POC (X5-02 pin 3)
 IaMax <10 mA
4.1.3 Analog output / load output X74 pin 3
Accuracy of output voltage ±1%
