USO RESTRITO
120
Basic DME Wipe Setting Operations for Independent Key Transitions
Chapter
6
DME
Wipes
Setting the DME wipe pattern size (Size)
For details about applicable pattern numbers, see “Size” in
“DME Wipe Pattern Variations and Modifiers”
( 1 p. 114).
1 In the Key1 DME Wipe Adjust menu, press [Size],
turning it on.
2 Set the following parameter.
No.
Parameter
Adjustment
1
Size
Effect size
a)
a) The effect size when [Size] is off is taken as 100.00%.
Adjusting the wipe pattern cropping (Crop)
1 In the <Crop Mode> group of the Key1 DME Wipe
Adjust menu, press [Crop], turning it on.
2 Set the following parameters.
Parameter group [1/2]
No.
Parameter
Adjustment
1
H
Crop the left and right of the
(“Left” value is displayed)
2
V
Crop the top and bottom of the
(“Top” value is displayed)
3
All
Crop the top, bottom, left, and
right of the image
(“Left” value is displayed)
Parameter group [2/2]
No.
Parameter
Adjustment
1
Top
Crop the top of the image
2
Left
Crop the left of the image
3
Right
Crop the right of the image
4
Bottom
Crop the bottom of the image
To crop to 4:3 aspect ratio in 16:9 mode
In the <Crop Mode> group, press [4:3 Crop], turning it on.
To set the operation for DME wipe crop transition
execution
1 In the <Crop Mode> group of the Key1 DME Wipe
Adjust menu, press [Crop], turning it on.
2 In the <Crop Mode> group, press [Crop] or [4:3 Crop]
(to crop from 16:9 to 4:3 aspect ratio), turning it on.
3 In the <Crop Mode> group, press [Remove From
Begin].
The Remove From Begin menu (1116.7) appears.
For subsequent operations, see step 5 in “To set the
action when a DME wipe crop transition is executed”
( 1 p. 118).
To set the timing of transition completion
1 In the <Crop Mode> group of the Key1 DME Wipe
Adjust menu, press [Crop], turning it on.
2 In the <Crop Mode> group, press [Remove From
Begin].
The Remove From Begin menu (1116.7) appears.
For subsequent operations, see step 3 in “To set the
timing of transition completion” ( 1 p. 118).
Modifying the DME wipe pattern edge
(Edge)
1 In the <Edge> group of the Key1 DME Wipe Adjust
menu, select one of the following.
Border
Soft Border
2 Set the following parameters.
When Border is selected
No.
Parameter
Adjustment
1
Width
Border width
3
Luminance
Luminance of border color
4
Saturation
Saturation
5
Hue
Hue
When Soft Border is selected
No.
Parameter
Adjustment
1
Width
Border width
2
Inner Soft
Border inner softness
3
Luminance
Luminance of border color
4
Saturation
Saturation
5
Hue
Hue
Specifying DME wipe direction
For details about the corresponding pattern number,
1 “DME Wipe Pattern Variations and Modifiers”
(p. 114).
Select one of the following in the <Direction> group of the
Key1 DME Wipe Adjust menu.
Normal: Wipes in the normal direction.
Normal/Reverse: Switches between normal and reverse
for each transition.
Reverse: Wipes in the opposite direction to normal.
