USO RESTRITO
372
Serial Port Settings
Chapter
21
DCU
Setup
For a player, the output port setting.
For a recorder, the input port setting.
2. Maximum Open Delay: Maximum time required to
open a file
3. Maximum Cueup Delay: Maximum time required to
cue up a file
4. Play After Cueup Delay: Delay time from the cued-
up state to begin playback
5. Stop Delay: Delay time from issuing the Stop
command until actually stopping
6. Still Delay: Delay time from issuing the Still
command until actually stopping
7. Continue Delay: Delay time from issuing the
Continue command until actually stopping
8. Idle Delay: Delay time from unloading a file until
entering the idle state
The idle state is a state wherein a file has been
unloaded but a new file has not been loaded yet, that
is, a state wherein no file is loaded.
9. Status Sense Interval: Time until the next Status
Sense command is issued (Simple VDCP Setting
menu only)
9 Set the disk recorder video port number or response
speed.
When setting the video port number
No.
Parameter
Adjustment
2
Setting
Video port number
When setting the response speed
No.
Parameter
Adjustment
2
Setting
Response speed setting
10 Press [Set].
11 Repeat steps 8 to 10 as required to make the settings
for other items.
To enable or disable the loop and recue functions
Press [Loop] or [Recue] to enable/disable the loop and
recue functions, respectively.
Loop: Replays the recalled file in a continuous loop.
Recue: After playing the recalled file, recues to the
beginning and then stop.
Making detailed settings for an Extended
VTR
1 In the Engineering Setup >DCU >Serial Port Assign
menu (7355), select the setting target (DCU1 or
DCU2) from the <DCU Select> group.
2 Select the serial port connected to the extended VTR
for which you want to make the settings.
Notes
When the MKS-2700 is connected, select 2 for the slot
and a value in the range 1 to 6 for the port.
3 Press [Port Setting].
The Extended VTR Setting menu (7355.5) appears. At
the top of the status area, the relevant serial port, slot
number, device type, serial port name, and SCU
number appear. In the lower part of the status area, the
response speed settings appear.
4 Specify the item to which the response speed setting
applies.
1. Maximum Open Delay: Maximum time required to
open a file
2. Maximum Cueup Delay: Maximum time required to
cue up a file
3. Play After Cueup Delay: Delay time from the cued-
up state to begin playback
4. Stop Delay: Delay time from issuing the Stop
command until actually stopping
5 Set the response speed of the Extended VTR.
No.
Parameter
Adjustment
2
Setting
Response speed setting
6 Press [Set].
7 Repeat steps 4 to 6 as required to make the settings for
other items.

Sony MVS-6530 Specifications

General

BNC input ports	48
BNC output ports	32
RJ-45 input ports	4
Product color	Black
AC input voltage	100 - 240 V
AC adapter frequency	50/60 Hz
AC adapter input current	4 A
Storage temperature (T-T)	-20 - 55 °C
Operating temperature (T-T)	5 - 40 °C

Weight and Dimensions

Depth	486 mm
Width	482 mm
Height	176 mm
Weight	21000 g
