Macro File Editing Rules
Symbol
Parameter name
Arguments
Description
PatternLimit
ME?
ME1, PP
Control blocks on the applicable bank
Status?
ToOn (a),
ToOff (b),
Any (c)
Pattern limit status
(a): Pattern limit applies
(b): Pattern limit does not apply
(c): The pattern limit status always changes
TransitionType
ME?
ME1, PP
Control blocks on the applicable bank
TransitionType?
Mix, NAM, SuperMix,
PresetColorMix, Wipe,
DMEWipe,
FM1&2Clip, FM3&4Clip,
FM5&6Clip, FM7&8Clip
Transition type
KeyTransitionType
ME?
ME1, PP
Control blocks on the applicable bank
Key?
Key1 to Key4
Key of the applicable independent key transition
Direction?
On (a),
Off (b),
Any (c)
Independent key transition execution mode
(a): Key is inserted
(b): Key is deleted
(c): Transition is always executed
KeyTransitionType?
Mix, Wipe, DMEWipe, Cut
Transition type of the independent key transition
NextTransition
ME?
ME1, PP
Control blocks on the applicable bank
All?
On, Off
Applicable next transition
KeyPriority?
On, Off
Applicable next transition
BKGD?
On, Off
Applicable next transition
Key1? to Key8?
On, Off
Applicable next transition
FadeToBlack
Time?
Current (a),
0 to 999
Transition rate (number of frames)
(a): Mode in which the current value set in fade
to black is used
TimelineDirectionNormal
Region?
ME1, PP,
User1 to User8,
DME1 to DME8, PBus,
Device1 to Device12,
GPI, Current (a)
Applicable region
(a): Mode in which operation takes place in the
region currently specified in the Flexi Pad
TimelineDirectionReverse
Region?
ME1, PP,
User1 to User8,
DME1 to DME8, PBus,
Device1 to Device12,
GPI, Current (a)
Applicable region
(a): Mode in which operation takes place in the
region currently specified in the Flexi Pad
TimelineNormalReverseOn
Region?
ME1, PP,
User1 to User8,
DME1 to DME8, PBus,
Device1 to Device12,
GPI, Current (a)
Applicable region
(a): Mode in which operation takes place in the
region currently specified in the Flexi Pad
TimelineNormalReverseOff
Region?
ME1, PP,
User1 to User8,
DME1 to DME8, PBus,
Device1 to Device12,
GPI, Current (a)
Applicable region
(a): Mode in which operation takes place in the
region currently specified in the Flexi Pad
UtilityButton
UtilityModule?
UserPrefs
User preference buttons
Button?
1 to 16
Applicable button
UtilityStatus?
On,
Off,
Current (a)
Status of function assigned to button
(a): Operates according to currently assigned
function
Appendix

Sony MVS-6530 Specifications

General

BNC input ports	48
BNC output ports	32
RJ-45 input ports	4
Product color	Black
AC input voltage	100 - 240 V
AC adapter frequency	50/60 Hz
AC adapter input current	4 A
Storage temperature (T-T)	-20 - 55 °C
Operating temperature (T-T)	5 - 40 °C

Weight and Dimensions

Depth	486 mm
Width	482 mm
Height	176 mm
Weight	21000 g
