Steris SYSTEM 1E Service Manual

2-6
764333-675
• Input
Select INPUT, then press SAVE VALUES touch pad.
Display shows:
lid FLT hpp CMP
Check for proper ON and OFF operation shown on
display (CAPITAL LETTERS = switch closed,
lowercase = switch open).
• LID = Lid switch (LS4)
• FLT = Float block switch (LS3)
• HPP = H.P. pump monitor pressure switch (LS6)
• CMP = Compressor control switch (LS5)
NOTE: Float block switch (LS3) and compressor
control switch (LS5) are normally closed. With lid down
and latched switch is open and display is “lid”
lowercase.
Press CANCEL when done. Display shows:
MFG TESTS
VALUES CALIB
Select TESTS, then press SAVE VALUES touch pad.
Display shows:
VALVES INPUT
CONSOLE MORE
•Console
CONSOLE allows checking of the keypad, dip switch
settings, and display.
Select CONSOLE, then press SAVE VALUES touch
pad. Display shows:
KEYPAD DIPSW
DISPLAY
• Keypad
Select KEYPAD, then press SAVE VALUES touch
pad. Display shows:
* KEYPAD TEST *
KEY =
Refer to the keypad chart. Press a key on the keypad.
If the communication link is functioning properly, the
corresponding number on the keypad displays.
NOTE: The CANCEL touch pad does not display a
number. The test for the cancel touch pad is that it exits
this routine when pressed.
Select CANCEL. Display shows:
MFG TESTS
VALUES CALIB
Select TESTS, then press SAVE VALUES touch pad.
Display shows:
0 1 2
3 4 5
6 7 8
9 15 10
16 17 18 19 20
21
XXXXXXXXX
START
23
CANCEL
