Steris SYSTEM 1E Service Manual

3-2
764333-675
Table 3-1. Component List
Flow Chart Name Common Name
Float Block Assembly
CK1 ....................... Air inlet check valve
CK2 ....................... Float block drain check
valve
CK3 ....................... Float block drain check
valve
LS3 ....................... Float block switch
FLT2...................... Sterile air filter
MaxPure™ Filter and Housing Assembly
FLT1 .............................Housing of MaxPure Filter
CK4 ....................... Backflow preventer
check valve
PT1 ....................... Pressure transducer
SOL8 ..................... Air-water solenoid valve
CK11 ..................... Circulation Check Valve
Air Manifold Assembly
CK5 ....................... Air manifold check valve
CK6 ....................... Air-water check valve (in
air manifold)
CK7 ....................... Air manifold check valve
LS2 ....................... Seal pressure safety
switch
LS5 ....................... Compressor control
switch
SOL1 ..................... Compressor release
solenoid
SOL2 ..................... Seal release solenoid
SOL3 ..................... Circulation pinch valve
solenoid
SOL4 ..................... Drain pinch valve
solenoid
Flow Chart Name Common Name
Drain Block Assembly
CK8 ....................... Drain check valve
TC3 ....................... Thermocouple #3 (drain
block assembly)
High Pressure Pump Assembly
CK9 ....................... Pressure relief valve
(internal to pump 2)
P2 ......................... High pressure pump
LS6........................ H.P. pump monitor
(pressure switch)
Heater Housing
HTR1 ..................... Heater element
LS1........................ Thermal Cutoff Switch
TC1 ....................... Thermocouple #1 (drain
transition block)
High Pressure Transition Block
CP1, CP2 ............... Concentration probes
TC2 ....................... Thermocouple #2 (high
pressure transition
block)
Flow Chart Name Common Name
Dual Water Inlet Assembly
SOL5 .....................Dump valve
SOL7 .....................Inlet fill valve
Miscellaneous Components
CK10......................Anti-siphon check valve
COMP1 ..................Air compressor
LS4 ........................Lid switch
P1..........................Circulation pump
S1..........................Inflatable seal
V5..........................Drain pinch valve
V6..........................Circulation pinch valve
UV System
UV2 .......................UV Chamber
UVM1 .....................UV intensity Monitor
Water Preparation System
PR1 .......................Water Pressure
Regulator
FLTA1 ....................Pre-Filter A
FLTB1 ....................Per-Filter B
Inflatable Seal
BH2 .......................Seal Emergency Relief
PR2 .......................Air Pressure Regulator
