Steris SYSTEM 1E Service Manual

5-3
764333-675
5.1 LIQUID CHEMICAL STERILIZATION CYCLE FAULTS
5.1.1 Wait For UV
Description - UV intensity is below 6.0 mA.
Action:
1. UV system unplugged – plug into receptacle.
2. Fouled (dirty) quartz sleeve – clean.
3. UV monitor harness not connected – plug into
connector on rear of processor.
4. Faulty UV monitor – replace.
5. Faulty UV lamp – replace.
6. Ballast circuit breaker tripped – reset.
7. Faulty UV lamp ballast – replace.
5.1.2 Temperature Under 43°C
Description - SYSTEM 1E™ Processor senses
incoming water temperature less than 43°C after four
minutes of water purge.
Action:
1. Check water supply is on.
2. Check water temperature is within specifications.
3. Check water filters are not clogged, replace.
4. Faulty SOL 5 valve, replace. (Refer to Figure 5-5.)
5. Faulty TC3, repair.
5.1.3 UV Intensity Timeout
Description: SYSTEM 1E Processor senses UV
intensity signal is below 15.0 mA after 10 minutes.
Action:
1. UV system unplugged – plug into receptacle.
2. Fouled (dirty) quartz sleeve – clean.
3. UV monitor harness not connected – plug into
connector on rear of processor.
4. Faulty UV monitor – replace.
5. Faulty UV lamp – replace.
6. Ballast circuit breaker tripped – reset.
7. Faulty UV lamp ballast – replace.
