Steris SYSTEM 1E Service Manual

2-12
764333-675
When the display shows:
MFG TESTS
VALUES CALIB
Select CALIB, then press SAVE VALUES touch pad.
Display shows:
CALIB RESTORE
VIEW PRINT
Select CALIB, then press SAVE VALUES touch pad.
Display shows:
PRESS TEMP
CONC MORE
Select TEMP, then press SAVE VALUES touch pad.
Display shows:
INLET OUTLET
DRAIN ALL
NOTE: TC1 = Thermocouple #1 (drain transition block),
TC2 = Thermocouple #2 (high pressure transition
block) and TC3 = Thermocouple #3 (drain block
assembly). Inlet and outlet as referenced to the heater.
Select one: INLET/OUTLET/DRAIN/ALL, then press
SAVE VALUES touch pad. Display shows:
WARNING! CALIB
WILL BE CHANGED
Printer prints Previous Values (see Figure 2-7). Press
SAVE VALUES touch pad. Display shows:
PLACE TC(S) IN
LO BATH PRESS SV
Place thermocouple(s) and temperature measuring
device in the cold water container and press SAVE
VALUES touch pad. Display shows:
==========================
=========INLET============
=========OUTLET==========
========= DRAIN =========
===== TEMPERATURE =======
===== CALIBRATION =======
=========================
AT X:XX:XX ON XX-XX-XX
PREVIOUS VALUES
INLET TEMPERATURE
LOW PT = XXXX
LOW RAW = XXXX
HIGH PT = XXXX
HIGH RAW = XXXXX
OUTLET TEMPERATURE
LOW PT = XXXX
LOW RAW = XXXX
HIGH PT = XXX X
HIGH RAW = XXXXX
DRAIN TEMPERATURE
LOW PT = XXXX
LOW RAW = XXXX
HIGH PT = XXXX
HIGH RAW = XXXXX
CALIBRATED VALUES
INLET TEMPERATURE
LOW PT = XXXX
LOW RAW = XXXX
HIGH PT = XXXX
HIGH RAW = XXXXX
OUTLET TEMPERATURE
LOW PT = XXXX
LOW RAW = XXXX
HIGH PT = XXXX
HIGH RAW = XXXXX
DRAIN TEMPERATURE
LOW PT = XXXX
LOW RAW = XXXX
HIGH PT = XXXX
HIGH RAW = XXXXX
Figure 2-7. Temperature Calibrated
Values
