FUEL SYSTEM AND THROTTLE BODY 5-11
• Remove the O-ring

B.
• Remove the TP sensor

C.
• Remove the IAP sensor

D.
• Disconnect the vacuum hose

E.
• Remove the fuel injector

F.
• Remove the intake pipe

G.
