SERVICING INFORMATION 10-37
FI SYSTEM AND INTAKE AIR SYSTEM
COOLING SYSTEM
CHASSIS
ITEM
N·m kgf-m
CKP sensor bolt 5 0.5
HO2 sensor 48 4.8
Fuel pump retainer 35 3.5
TP sensor mounting screw 1.8 0.18
ITEM
N·m kgf-m
Cooling fan thermo-switch 12 1.2
Engine coolant temperature gauge 13 1.3
Water pump mounting bolt 10 1.0
Cooling fan mounting bolt 8.4 0.84
ECT sensor 18 1.8
Thermostat case bolt 10 1.0
Engine coolant temperature gauge 13 1.3
Radiator hose clamp screw 2 0.2
ITEM N·m kgf-m
Handlebar set bolt 25 2.5
Handlebar clamp bolt/nut 50 5.0
Front fork lower bracket bolt
23 2.3
Steering stem nut
30 3.0
Front axle nut 44 4.4
Brake disc bolt (Front and Rear) 23 2.3
Brake caliper air bleeder valve (Front and Rear) 6 0.6
Brake caliper mounting bolt (Front and Rear) 26 2.6
Brake pad bolt (Front and Rear) 18 1.8
Brake hose union bolt (Front and Rear) 23 2.3
Brake pipe nut 16 1.6
Brake master cylinder bolt (Front and Rear)
Upper 12 1.2
Lower
10 1.0
Rear shock absorber bolt/nut (Upper and Lower) 29 2.9
Rear axle nut 120 12.0
Side-stand mounting bolt 10 1.0
Side-stand mounting nut 40 4.0
Brake lever pivot bolt/nut 6 0.6
