CHASSIS 8-39
• Remove the brake pad springs

4 and

5.
• Using an air blow gun, pressurize the caliper fluid chamber to
push out the pistons.
• Blow the hole

A to push out the center piston.
• Blow the hole

B to push out the upper and lower pistons.
)
• Remove the dust seals

6 and piston seals

7.
#
* Place a rag over the pistons to prevent them from
popping out and keep hand off the pistons.
* Be careful of brake fluid which can possibly splash.
* Do not use high pressure air but increase the pres-
sure gradually.
* Use care not to cause scratch on the cylinder bore.
* Do not reuse the piston seals and dust seals that
have been removed.
