ELECTRICAL SYSTEM 9-9
Step 4
1) Measure the resistance of the generator coil. (!9-11)
Is the resistance of generator coil OK?
Step 5
1) Measure the generator no-load performance. (!9-11)
Is the generator no-load performance OK?
Step 6
1) Inspect the regulator/rectifier. (!9-12)
Is the regulator/rectifier OK?
Step 7
1) Inspect wirings.
Is the wirings OK?
Battery overcharges
• Faulty regulator/rectifier
• Faulty battery
• Poor contact of generator lead wire coupler
YES Go to Step 5.
NO
• Faulty generator coil
• Disconnected lead wires
YES Go to Step 6.
NO Faulty generator
YES Go to Step 7.
NO Faulty regulator/rectifier
YES Faulty battery
NO
• Short circuit of wire harness
• Poor contact of couplers
To Next Page
