GSX-R750K2 (’02-MODEL) 11-33
FRONT BRAKE HOSE ROUTING
Clamp the brake hose firmly.
42˚42˚
After touching the brak
e hose unions
to the stopper, tighten the union bolts.
After touching the brake hose unions to the stopper tighten the union bolts.
Insert the clamp to the hole of the front fender fully.
The green paint is right side and face upside.
Left Right
42˚42˚
Clamp the brake hose firmly.
After positioning the clamp with the stopper,tighten the clamp bolt.
Pass through the brake hose behind the throttle cables.
15˚
Face the clamp ends backward.
Face the clamp ends down.
