0B-11 Maintenance and Lubrication:
Fuel Line Inspection
B822H10206007
Inspect fuel line
Every 6 000 km (4 000 miles, 12 months)
Inspect the fuel line in the following procedures:
1) Remove the seat. Refer to “Exterior Parts Removal
and Installation in Section 9D (Page 9D-3)”.
2) Remove the fuel tank mounting bolts. Refer to “Fuel
Tank Removal and Installation in Section 1G
(Page 1G-8)”.
3) Lift up the fuel tank.
4) Inspect the fuel feed hose for damage and fuel
leakage. If any defects are found, the fuel feed hose
must be replaced.
5) After finishing the fuel feed hose inspection, reinstall
the removed parts.
Evaporative Emission Control System
Inspection (E-33 Only)
B822H10206008
Inspect evaporative emission control system
Every 12 000 km (7 500 miles, 24 months)
Inspect the evaporative emission control system
periodically (E-33 only).
Engine Oil and Filter Replacement
B822H10206009
Replace engine oil
Initially at 1 000 km (600 miles, 2 months) and every
6 000 km (4 000 miles, 12 months) thereafter
Replace oil filter
Initially at 1 000 km (600 miles, 2 months) and every
18 000 km (11 000 miles, 36 months) thereafter
Oil should be changed while the engine is warm. Oil filter
replacement at the above intervals, should be done
together with the engine oil change.
Engine Oil Replacement
Motorcycle on the upright position
1) Keep the motorcycle upright with a jack or wooden
block.
2) Place an oil pan below the engine, and drain engine
oil by removing the oil drain plugs (1) and filler cap
(2).
I822H1020010-03
1
I822H1020027-02
2
I822H1020028-01
To Next Page
