Suzuki VLR1800 Service Manual

Rear Suspension: 2C-2
Rear Suspension Assembly Construction
B822H12306002
RHLH
(a)
1
(a)
1
(a)
1
(c)
4
(c)
4
(b)
2
(b)
3
(b)
3
(c)
4
(b)
2
(a)
1
6
5
(d)
“a” “a”
“a” “a”
I822H1230038-05
1. Rear shock absorber nut 5. Swingarm pivot shaft
: Tighten (5) first, and then tighten (6).
: 132 N⋅m (13.2 kgf-m, 95.5 lb-ft)
2. Rear cushion lever upper nut 6. Swingarm pivot shaft clamp bolt
: Tighten (5) first, and then tighten (6).
:110 N⋅m (11.0 kgf-m, 79.5 lb-ft)
3. Rear cushion lever lower nut “a”: 4.5 mm (0.2 in) : 100 N⋅m (10.0 kgf-m, 72.5 lb-ft)
4. Rear cushion rod nut : 65 N⋅m (6.5 kgf-m, 47.0 lb-ft) : Apply grease to the bearing.
