TB8100 Service Kit User’s Manual Configuration Tutorial 27
6. Make any other changes to the default channel profile, and click OK.
Step 5: Configure a Channel
1. In the navigation pane, under Base Station, click Channel Table.
2. Decide which channel the base station will operate on.
3. In that channel’s row, enter receive and transmit frequencies.
4. Click in the Receive Signalling cell and select a CTCSS tone or DCS
code. Do the same for Transmit Signalling.
5. Use the scroll bar to display the hidden columns in the table.
6. In the Filter column, select Pre-De-Emph Speech Band.
7. In the Channel Spacing column, select an option.
8. Click OK.
Step 6: Set the Default Channel.
1. Return to the General form.
2. In the Default channel area, select the channel you configured.
3. Click OK.
Step 7: Program the Changes into the Base Station
1. Click Save to save your changes to a file, giving it a suitable name.
2. Press F5 to put the base station in Standby mode.
3. Click Program. The Programming dialog box appears and indicates
progress.
When all the configuration information has been downloaded, it is
programmed into the base station. When the Service Kit receives
confirmation of this, it closes the dialog box.
4. Press F6 to return the base station to Run mode. It is now operational.
