Specifications
23
Liquid Injection Valve (Compressor):
Voltage 24 Vac
Current 0.85 amps
Cold Resistance 5.6 ohms
Warm Gas Bypass Solenoid Valve:
Voltage 24 Vac
Current 0.85 amps
Cold Resistance 5.6 ohms
Stepper Valve Regulating Motor:
Voltage 12 Vdc
Current Draw 0.13 to 0.21 amperes per winding
0.26 to 0.44 amperes with 2 windings energized
Resistance 75 ± 7.5 ohms across each winding at 24 C (75 F) ambient
Water Pressure Switch (Option):
Close 117 ± 21 kPa, 1.17 ± 0.20 bar, 17 ± 3 psig
Open 35 ± 21 kPa, 0.35 ± 0.20 bar, 5 ± 3 psig
*When the compressor is removed from the unit, oil level should be noted or the oil removed from the compressor should be
measured so that the same amount of oil can be maintained in the replacement compressor.
**Do not use or add standard synthetic or mineral oils to the refrigeration system. If Ester based oil becomes contaminated
with moisture or with standard oils, dispose of properly — Do Not Use!
Refrigeration System (Continued)
Normal R-404A System Operating Pressures (Scroll Compressor)
Container
Temp.
Operating
Mode
Ambient
Temp.
Suction Pressure Discharge Pressure
21 C (70 F) Cool
27 to 38 C, 80
to 100 F
410 to 670 kPa, 4.10 to 6.70
bar, 59 to 97 psig
2140 to 2650 kPa, 21.40 to
26.50 bar, 310 to 385 psig
16 to 27 C, 60
to 80 F
400 to 600 kPa, 4.00 to 6.00
bar, 58 to 87 psig
1725 to 2140 kPa, 17.25 to
21.40 bar, 250 to 310 psig
2 C (35 F) Cool
27 to 38 C, 80
to 100 F
385 to 425 kPa, 3.85 to 4.25
bar, 56 to 62 psig
1860 to 2380 kPa, 18.60 to
23.80 bar, 270 to 345 psig
16 to 27 C, 60
to 80 F
345 to 385 kPa, 3.45 to 3.85
bar, 50 to 56 psig
1450 to 1860 kPa, 14.50 to
18.60 bar, 210 to 270 psig**
-18 C (0 F) Cool
27 to 38 C, 80
to 100 F
214 to 228 kPa, 2.14 to 2.28
bar, 31 to 33 psig
1515 to 2035 kPa, 15.15 to
20.35 bar, 220 to 295 psig**
16 to 27 C, 60
to 80 F
200 to 215 kPa, 2.00 to 2.15
bar, 29 to 31 psig
1100 to 1515 kPa, 11.00 to
15.15 bar, 160 to 220 psig**
-29 C (-20 F) Cool
27 to 38 C, 80
to 100 F
145 to 160 kPa, 1.45 to 1.60
bar, 21 to 23 psig
1450 to 1965 kPa, 14.50 to
19.65 bar, 210 to 285 psig**
16 to 27 C, 60
to 80 F
130 to 145 kPa, 1.30 to 1.45
bar, 19 to 21 psig
1035 to 1450 kPa, 10.35 to
14.50 bar, 150 to 210 psig**
*Suction and discharge pressures vary too greatly during Modulation Cool to use for evaluating or diagnosing refrigeration
system performance. During the Modulation Cool mode, the suction pressure will vary between 100 and 450 kPa, 1.0 and
4.5 bar, 15 and 65 psig depending upon the percent (%) cooling capacity.
**Discharge pressure is determined by condenser fan cycling.
