Unit Description
44
AXA0234
1
2
3
4
5
9
8
7
6
1. Gasket 6. Interface Board and Cable (Mounts in Control Box),
see page 42
2. Vent Door Assembly 7. Stop Bracket, Vent Door Full Open
3. Linkage Assembly 8. Stop Bracket, Vent Door Closed
4. Damper Motor Housing 9. Grille
5. Damper Motor Assembly Mounting Bracket
Figure 14: Advanced Fresh Air Management (AFAM) Option
