Thermo King CSR Series User Manual

Unit Description
33
1
2
3
4
5
6
7
8
11
AXA0221
9
10
1. CSR20SL & CSR40SL: Evaporator Access Door, 1399 mm (55.04 in.) Wide with three latches
2. CSR40: Evaporator Access Door, 1018 mm (40.08 in.) Wide with two latches
3. Heater Access Panel Location (CSR20SL-144 , CSR20SL-155 , CSR40-145 & CSR40SL-506 Models Only)
4. Condenser Fan
5. Compressor Compartment
6. Supply Air Sensor Probe Holder, Left Hand (Behind Compressor)
7. Supply Air Sensor Probe Holder, Right Hand
8. Power Cord Storage Compartment
9. Control Box
10. Rear Download and USDA Receptacle Panel (Access from Inside Container)
11. Fresh Air Exchange Vent
Figure 3: Typical Unit Front View
