Unit Description
47
AXA0237
1
2
4
5
6
3
1. TRANSFRESH Scrubber Connection and A5 Wire Harnesses
2. Evaporator Grille
3. TRANSFRESH Security Enclosure
4. Transformer Assembly mounted in Control Box
5. TRANSFRESH Download Port
6. Purge Port
Figure 17: TRANSFRESH System, Complete
