Toshiba e-studio555 User Manual

e-STUDIO555/655/755/855 © 2009 - 2011 TOSHIBA TEC CORPORATION All rights reserved
REVERSING AUTOMATIC DOCUMENT FEEDER (RADF)
15 - 8
15.4 Electric Circuit Description
15.4.1 Signal block diagram
Fig. 15-4
Equipment
CPU
RADF
Driver
Driver
Driver
Driver
Driver
Driver
Driver
Driver
Original feed motor
(
MR1
)
Read motor
(
MR2
)
Original reverse motor
(
MR3
)
Original exit motor
(
MR4
)
RADF cooling fan
(FR
1
)
Original pickup solenoid
(
SOLR1
)
Original reverse solenoid
(SOLR2)
Original exit solenoid
(
SOLR3
)
Original tray sensor
(
SR1
)
Original tray width sensor
(
SR2
)
Original empty sensor
(
SR3
)
Original reading end sensor
(
SR4
)
Original registration sensor
(
SR5
)
Original width detection sensor-1
(
SR6
)
Original width detection sensor-2
(
SR7
)
Original width detection sensor-3
(
SR8
)
Original intermediate transport sensor
(
SR9
)
Original reading start sensor
(
SR10
)
Original exit/reverse sensor
(
SR11
)
Original exit sensor
(
SR12
)
Original jam access cover opening/closing sensor (SR13)
Original reverse unit opening/closing sensor (SR14)
Jam access cover opening/closing sensor
(
SWR1
)
RADF opening/closing switch
(
SWR2
)
RADF opening/closing sensor
(
SR15
)
Downlad jig
Reset IC
DC 24V
DC 5V
CPU

Toshiba e-studio555 Specifications

Power

power supply	120 Volts; 20 Amps
power consumption	Maximum 2.0kW
warm-up time	Appx. 130 Seconds

Printing and Copying

copy/print resolution	2400 x 600 dpi
copy/print speed	55 / 65 / 75 / 85 cpm
print speed	55 / 65 / 75 / 85 ppm

Scanning

scan speed	80 spm LT-Size @300 dpi
scan resolution	150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi
file format	TIFF, PDF, JPEG, XPS, MS Word, MS Excel, Searchable PDF w/ Adv. Scanning option

Memory and Storage

memory	1GB RAM, 60 GB HDD
fax memory transmission	500MB (HDD)
reception	500MB (HDD)

Connectivity

connectivity	Ethernet 10/100BaseT, USB 2.0, 802.11b/g Wireless LAN, Bluetooth (HCRP)
protocol support	IPX/SPX, TCP/IP (IPV4/V6), EtherTalk, AppleTalk PAP, LPR/LPD, IPP w/Authentication, Port 9100
operating systems	Windows 2000/XP/2003/Vista/2008, Mac X OS 10.2.4/10.3/10.4/10.5, UNIX, Linux, CUPS

Weight and Dimensions

dimensions	28” x 31” x 46” (W x D x H)
weight	462 lbs
standard paper supply	2 x 500-Sheet Drawer; 2 x 1, 250-Sheet Tandem Drawer; 100-Sheet Stack Feed Bypass
