Toshiba e-studio555 User Manual

e-STUDIO555/655/755/855 © 2009 - 2011 TOSHIBA TEC CORPORATION All rights reserved
POWER SUPPLY UNIT
16 - 8
16.5 Configuration of Power Supply Unit
Fig. 16-1
CN401 CN413
CN414
Noise
filter
AC
shut off
detection
S-line
transformer
(AC/DC)
Cover
interlock
switch
Main switch
RLY1 RLY2
RLY3 RLY4
Switching regulator
Main switch
line
transformer
(AC/DC)
Cover switch
line
transformer
(AC/DC)
Noise
filter
Filter
F2 F3
Noise
filter
Noise
filter
Inlet
Control circuit
PWR-DN 5VS RLY-ON SYS-EN PWR-EN 12VA 12VB 5VA 5VB 5VB (to LGC board) 3.3VB 36VD 24VD1 24VD2 24VD3 24VD4 5VD 5VSW 5VB
to IH board
SW SW
Reg-IC
12V
5V
36V 24V
F8 F9 F5 F7
F6 F4
Reg-IC
to Damp heater
Breaker

Toshiba e-studio555 Specifications

Power

power supply	120 Volts; 20 Amps
power consumption	Maximum 2.0kW
warm-up time	Appx. 130 Seconds

Printing and Copying

copy/print resolution	2400 x 600 dpi
copy/print speed	55 / 65 / 75 / 85 cpm
print speed	55 / 65 / 75 / 85 ppm

Scanning

scan speed	80 spm LT-Size @300 dpi
scan resolution	150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi
file format	TIFF, PDF, JPEG, XPS, MS Word, MS Excel, Searchable PDF w/ Adv. Scanning option

Memory and Storage

memory	1GB RAM, 60 GB HDD
fax memory transmission	500MB (HDD)
reception	500MB (HDD)

Connectivity

connectivity	Ethernet 10/100BaseT, USB 2.0, 802.11b/g Wireless LAN, Bluetooth (HCRP)
protocol support	IPX/SPX, TCP/IP (IPV4/V6), EtherTalk, AppleTalk PAP, LPR/LPD, IPP w/Authentication, Port 9100
operating systems	Windows 2000/XP/2003/Vista/2008, Mac X OS 10.2.4/10.3/10.4/10.5, UNIX, Linux, CUPS

Weight and Dimensions

dimensions	28” x 31” x 46” (W x D x H)
weight	462 lbs
standard paper supply	2 x 500-Sheet Drawer; 2 x 1, 250-Sheet Tandem Drawer; 100-Sheet Stack Feed Bypass
