© 2009 - 2011 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO555/655/755/855
OUTLINE OF THE MACHINE
2 - 37
2.3.4 Solenoids
2.3.5 PC boards
CLT12 CST4-FEED-CLT
4th drawer feed clutch
Driving the separation roller, feed roller and
pickup roller of the 4th drawer
(Only for JPC model of all equipments)
Fig. 2-21 7-26
Symbol Name Function Remarks P-I
SOL1 SPRT-FING-SOL
Drum separation finger
solenoid
Driving the drum separation fingers Fig. 2-14 31-17
SOL2 GATE-SOL
Gate solenoid
Driving the exit/reverse gate Fig. 2-17 15-2
SOL3 SFB-SOL
Bypass pickup solenoid
Driving the lifting movement of the bypass
pickup roller
Fig. 2-20 10-8
SOL7 LCF-PICK-SOL
Tandem LCF pickup
solenoid
Driving the lifting movement of the tandem
LCF pickup roller
(Only for NAD/SAD/ARD/ASD/AUD/MJD/
CND/TWD model of all equipments)
Fig. 2-21 7-36
SOL8 LCF-ENDF-SOL
Tandem LCF end fence
solenoid
Driving of the lever to detect the paper mis-
stacking at the standby side of the tandem
LCF
(Only for NAD/SAD/ARD/ASD/AUD/MJD/
CND/TWD model of all equipments)
Fig. 2-22 8-9
SOLR1 Original pickup solenoid Drives up and down the original pickup
roller.
Fig. 2-29 89-10
SOLR2 Original reverse solenoid Drives the reverse flapper. (Switches the
flapper to the reverse side when turned to
ON.)
Fig. 2-29 89-13
SOLR3 Original exit solenoid Drives the exit flapper. (Switches the
flapper to the original reverse tray side
when turned to ON.)
Fig. 2-29 89-13
Symbol Name Function Remarks P-I
CCD PWA-F-CCD
CCD driving PC board
(CCD board)
Scanning originals with CCD Fig. 2-5
Fig. 2-6
34-1
SLG PWA-F-SLG
Scanning section control
PC board (SLG board)
Controlling the scanning section Fig. 2-5
Fig. 2-6
38-1
DSP PWA-F-DSP
Display PC board
(DSP board)
Controlling the whole control panel Fig. 2-8 3-24
KEY PWA-F-KEY1
Key PC board
(KEY board)
Mounting the key switches and LEDs Fig. 2-8 3-16
PLG PWA-H-PLG
Laser control PC board
(PLG board)
Controlling the laser unit Fig. 2-9
Fig. 2-10
32-7A
32-7B
LDR1 PWA-F-LDR1
Laser driving PC board-1
(LDR1 board)
Driving the laser diode Fig. 2-9
Fig. 2-10
32-1A
32-1B
LDR2 PWA-F-LDR2
Laser driving PC board-2
(LDR2 board)
Driving the laser diode
(Only for e-STUDIO755/855)
Fig. 2-10 32-1B
SNS PWA-F-SNS
H-sync detection PC board
(SNS board)
Detecting the laser beam position Fig. 2-9
Fig. 2-10
32-1A
32-1B
Symbol Name Function Remarks P-I

Toshiba e-studio555 Specifications

Power

power supply	120 Volts; 20 Amps
power consumption	Maximum 2.0kW
warm-up time	Appx. 130 Seconds

Printing and Copying

copy/print resolution	2400 x 600 dpi
copy/print speed	55 / 65 / 75 / 85 cpm
print speed	55 / 65 / 75 / 85 ppm

Scanning

scan speed	80 spm LT-Size @300 dpi
scan resolution	150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi
file format	TIFF, PDF, JPEG, XPS, MS Word, MS Excel, Searchable PDF w/ Adv. Scanning option

Memory and Storage

memory	1GB RAM, 60 GB HDD
fax memory transmission	500MB (HDD)
reception	500MB (HDD)

Connectivity

connectivity	Ethernet 10/100BaseT, USB 2.0, 802.11b/g Wireless LAN, Bluetooth (HCRP)
protocol support	IPX/SPX, TCP/IP (IPV4/V6), EtherTalk, AppleTalk PAP, LPR/LPD, IPP w/Authentication, Port 9100
operating systems	Windows 2000/XP/2003/Vista/2008, Mac X OS 10.2.4/10.3/10.4/10.5, UNIX, Linux, CUPS

Weight and Dimensions

dimensions	28” x 31” x 46” (W x D x H)
weight	462 lbs
standard paper supply	2 x 500-Sheet Drawer; 2 x 1, 250-Sheet Tandem Drawer; 100-Sheet Stack Feed Bypass
