4 Replacement Procedures 4.2 Battery pack
4.2 Battery pack
Removing the battery pack
The following describes the procedure for removing the battery pack (See Figure 4-1 and 4-
2).
CAUTION: Take care not to short-circuit the terminals when removing the battery pack.
Similarly, do not drop, knock, scratch, disassemble, twist, or bend the battery
pack.
1. Turn off the power of the computer.
2. Disconnect the AC adapter and all external devices from the computer.
3. Turn the computer upside down.
4. Release the battery lock.
Battery lock
Figure 4-1 Removing the battery pack (1)
4-10 [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)
