Appendix B Boar
d Layout
Appendices
B.5
Power SW board (FDUPW*) View
(front)
(back)
Figure B-5 Power SW board (F
DUPW*) layout (front/back)
Table B-
5
Power SW
board (F
DUPW
*) connector (
back
)
Number Name
CN3310
System board I/F connector
QOSMIO G50 Maintenance Manual (960-683)
[CONFIDENTIAL]
B-7
