Toshiba QOSMIO G50 Maintenance Manual

Appendices Appendix B Board Layout
B.4 LED board (FDULE*) View
(front)
(back)
Figure B- 4 LED board (F DULE *) layout (front/back)
Table B- 4 LED board (F DULE *) connector s (back)
Number Name
CN3340 Touch PAD I/F connector
CN9510 System board I/F connector
CN9511 FDUFS* I/F connector
B-6 [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)
