Toshiba QOSMIO G50 Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-21
C.26 CN4630 FDUJK* board interface connector (8-pin)
Table C-26 FDUJK* board interface connector (8-pin)
Pin No. Signal Name Pin No. Signal Name
1 USB1PS-E5V 2 ZUSB11-E3P
3 ZUSB11-E3N 4
GND
5
GND
6
ZUSBP8-E3P
7
ZUSBP8-E3N
8
USB1PS-E5V
C.27 CN4631 FDUJK* board interface connector (20-pin)
Table C-27 FDUJK* board interface connector (20-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 DOUT-P3P
3 SPD3V-P3V 4
SPDJIN-P3N
5
GND
6
GND
7
NC
8
HEADR-PXP
9
GND
10
HEADL-PXP
11
GND
12
SPKEN-P4P
13
EMICB-P2V
14
DETCTA-P4N
15
A4R7-P4V
16
R3V
17
EMCINR-PXP
18
GND
19
EMCINR-PXP
20
GND
1T
GND
2T
GND
