1.6.2 FL Inverter Board
The FL inverter board supplies a high frequency current to illuminate the LCD module FL.
Table 1-8 lists the FL inverter board specifications.
Table 1-5 FL inverter board specifications
Specifications
Item
G71C0007Y110:
T
wo lights
G71C0007Y210:
Two lights
G71C0007Y510:
One light
Voltage (V) 5 (DC) Input
Power (W) 18
Voltage (V) 900 (rms)
Power (W/VA)
7 / 10 (Dual：x 2 outp
ut)
Current
(f=70KHz)(mA)
7 (rms) (Single/Dual)
Output
Open
voltage(V
)
1550 (rms) (x 2
output)
1660 (rms)
