Toshiba QOSMIO G50 Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-29
C.39 CN9550 Web Camera interface connector (8-pin)
Table C-39 Web Camera interface connector (10-pin)
Pin No. Signal Name Pin No. Signal Name
1 P5V 2 ZUSBP2-E3P
3
ZUSBP2-E3N
4
GND
5
GND
6
GND
7
INTMIC-PXP
8
IMIC-GND
C.40 CN9570 FELICA interface connector (6-pin) :Japanese model
Only
Table C-40 FELICA interface connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1 E5V 2 ZUSBP5-E3N
3
ZUSBP5-E3P
4
GND
5
NC
6
GND
1T
GND
2T
GND
C.41 CN9650 Touch Sensor interface connector (10-pin)
Table C-41 Touch Sensor interface connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 GND
3
GND
4
SSCL-S3P
5
TC-S5V
6
SSDA-S3P
7
TC-S5V
8
TC-S5V
9
NC
10
NC
1T
GND
2T
GND
