Appendices Appendix C Pin Assignments
C-36 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
LED board (FDULE*)
C.55 CN3340 Touch PAD interface connector (12-pin)
Table C-55 Touch PAD interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
1
LEFT-SW
2
NC
3 NC 4 P5V
5 NC 6 RIGHT-SW
7 GND 8 GND
9 IPDCLK-P5P 10 IPDDAT-P5P
11 P5V 12 P5V
1T GND 2T GND
C.56 CN9510 System board interface connector (30-pin)
Table C-56 System board interface connector (30-pin)
Pin No. Signal Name Pin No. Signal Name
1
GND
2
RCIRRX-S3P
3 RFLED-S5N 4 WMLED-S5N
5 P5V 6 LERNRX-P5N
7 PDLEON-S3P 8 FMLED-P5N
9 RFSWON-S3N 10 RECRED-S5N
11 RECORG-S5N 12 SATLED-P5N
13 BAT1GR-S5N 14 BAT1OR-S5N
15 M5V 16 PWLEGR-S5N
17 PWLEOR-S5N 18 E3V
19 DCINGR-S5N 20 DCINOR-S5N
21 GND 22 PGSPON-S3N
23 GND 24 ZUSBFS-E3N
25 ZUSBFS-E3P 26 GND
27 GND 28 IPDDAT-P5P
29 IPDCLK-P5P 30 S3V
1T GND 2T GND
