Appendices Appendix C Pin Assignments
C-16 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
C.15 CN2800 PCI-E Mini CARD(slot4) interface connector (52-pin)
Table C-15 PCI-E Mini CARD(slot4) interface connector (52-pin)
Pin No. Signal Name Pin No. Signal Name
1 PEWAKE-E3N 2 P3V
3 NC 4 GND
5 NC 6 P1V
7 MN4XRQ-P3N 8 NC
9 GND 10 NC
11 XPEMN4-PON 12 NC
13 XPEMN4-P0P 14 NC
15 GND 16 NC
17 NC 18 GND
19 NC 20 NC
21 GND 22 PLTRS2-E3N
23 ZERMN4-P1N 24 E3V
25 ZERMN4-P1P 26 MN4PRS-P3N
27 GND 28 P1V
29 GND 30 TSCL-P3P
31 ZETMN4-P1N 32 TSDA-P3P
33 ZETMN4-P1P 34 GND
35 GND 36 NC
37 TMPSPR-GND 38 NC
39 TMPSPR-SXP 40 GND
41 SPTHRM-P3N 42 NC
43 SPCKLOW-P3N 44 NC
45 SALERT-P3P 46 NC
47 NC 48 P1V
49 NC 50 GND
51 NC 52 P3V
1T
GND
2T
GND
