Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-47
NB9E board (FDUNE*)
C.64 CN5960 System board interface connector (230-pin)
Table C-64 System board interface connector (230-pin)(1/4)
Pin No. Signal Name Pin No. Signal Name
1
PVT-EFV
2
NC
3 PVT-EFV 4 NC
5 PVT-EFV 6 NC
7 PVT-EFV 8 NC
9 PVT-EFV 10 NC
11 PVT-EFV 12 NC
13 PVT-EFV 14 1R8-P1V
15 PVT-EFV 16 GPON-E3P
17 GND 18 E5V
19 GND 20 GND
21 GND 22 GND
23 GND 24 GND
25 ZEGC15-P1N 26 PGVGD-P3P
27 ZEGC15-P1P 28 ZECG15-P1N
29 GND 30 ZECG15-P1P
31 ZEGC14-P1N 32 GND
33 ZEGC14-P1P 34 ZECG14-P1N
35 GND 36 ZECG14-P1P
37 ZEGC13-P1N 38 GND
39 ZEGC13-P1P 40 ZECG13-P1N
41 GND 42 ZECG13-P1P
43 ZEGC12-P1N 44 GND
45 ZEGC12-P1P 46 ZECG12-P1N
47 GND 48 ZECG12-P1P
49 ZEGC11-P1N 50 GND
51 ZEGC11-P1P 52 ZECG11-P1N
53 GND 54 ZECG11-P1P
55 ZEGC10-P1N 56 GND
57 ZEGC10-P1P 58 ZECG10-P1N
59 GND 60 ZECG10-P1P
61 ZEFGC09-P1N 62 GND
63 ZEGC01-P1P 64 ZECG09-P1N
65 GND 66 ZECG09-P1P
